An SMD (Surface Mount Device) bend nozzle is a specialized tool used in electronics manufacturing and repair, particularly in surface mount technology (SMT) processes. Here’s a detailed description:
Physical Appearance: An SMD bend nozzle typically resembles a thin, elongated tube with a small opening at the tip. Here are its key components:
- Nozzle Body: The main part of the bend nozzle is a slender tube, often made of metal or durable plastic. It’s designed to be lightweight and precise.
- Tip Opening: At the end of the nozzle, there’s a small opening where the component leads or legs are inserted for bending.
- Bend Angle: The bend nozzle’s tip is angled to allow for precise bending of component leads at specific angles, typically 45 or 90 degrees.
- Connector: Depending on the system it’s used with, the bend nozzle may have a connector that attaches it to a vacuum pump or a pneumatic system for controlled operation.
